HDMI-A connector ShiverPeaks 10-01056 metal, supports up to 8K resolution

Metal HDMI-A connector ShiverPeaks 10-01056 is a replacement or assembly plug designed for HDMI cables and AV installations. Specified to support up to 8K resolution, this metal-housed connector provides a stable mechanical connection and consistent signal transfer for displays, TVs, projectors and media players. The robust metal shell improves durability in frequent-use environments and helps maintain contact integrity for high-bandwidth video and audio signals.

Advantages

The metal construction offers enhanced mechanical strength and wear resistance compared with plastic housings, reducing deformation and contact issues over time. Engineered for high-speed digital signals, the connector is compatible with HDMI cable assemblies intended to carry up to 8K video and multi-channel audio. Its standardized HDMI-A form factor ensures compatibility with widely used HDMI ports on monitors, TVs and AV receivers while providing a compact profile for tight cable routing.

Suitable for

• Repairing or replacing damaged HDMI plugs on cables
• Building custom HDMI cable assemblies for AV installations
• Connecting high-resolution displays, TVs and projectors
• Professional and home media players requiring reliable HDMI connections

Key specifications

• Connector type: HDMI-A plug (standard size)
• Housing material: metal shell for improved durability
• Resolution support: specified for up to 8K video
• Signal support: high-speed digital video and multi-channel audio
• Compatibility: standard HDMI port form factor for displays and AV equipment

How to use

Prepare the HDMI cable conductors and shielding according to the chosen assembly method, then insert conductors into the connector contacts following the HDMI wiring scheme. Ensure the mating surfaces and contacts are clean and correctly aligned before crimping or soldering, depending on the connector variant and installation tools. After assembling, verify mechanical fastening of the metal shell and test the completed cable with an appropriate source and display to confirm 8K or intended resolution transfer performance.

Recommendations

Use suitable crimping or soldering tools and follow ESD-safe handling practices. For highest resolution performance, pair this connector with quality HDMI cable conductors and proper shielding. Inspect assembled connections for secure contact and test with target display equipment to confirm signal integrity.
