HARTTE SOLE-JUMPER 180KG (Surface + Closure Monitoring + LED Signaling)

The HARTTE SOLE-JUMPER 180KG is a high-durability pressure mat sensor designed for surface presence and contact closure monitoring with integrated LED signaling. Ideal for safety and automation applications, this sensor reliably detects human presence with a maximum load capacity of 180 kg.

Advantages

Robust PVC/Rubber composite construction ensures long-lasting performance in demanding environments. IP65 rating provides protection against dust and water jets, making it suitable for indoor and covered outdoor use. Selectable Normally Open (NO) or Normally Closed (NC) output configuration offers flexibility for integration into various control systems.

Suitable for

• Industrial safety mats
• Access control systems
• Automated door activation
• Presence detection in workspaces

Key specifications

• Product Type: Pressure Mat Sensor
• Detection Principle: Pressure-sensitive contact closure
• Maximum Load Capacity: 180 kg
• Monitoring Capabilities: Surface presence, Contact closure
• Signaling: Integrated LED indicator
• Output Configuration: Normally Open (NO) / Normally Closed (NC) selectable
• Operating Voltage: 12V DC - 24V DC
• Material: High-durability PVC/Rubber composite
• Ingress Protection (IP) Rating: IP65
• Operating Temperature Range: -10°C to +50°C
• Application Environment: Indoor/Outdoor (covered)
• Installation Type: Surface-mounted
• Connectivity: Wired
• Color: Black
• Response Time: < 100 ms
• Activation Force: Designed for human presence detection

Recommendations

For optimal performance, install on a flat, clean surface and ensure proper wiring according to the selected output configuration. Regularly inspect the mat for damage and test functionality.
