Harting protective hood housing model 09670090336, IP65, single-piece

Harting protective hood housing model 09670090336, IP65, single-piece is a single-piece hood designed to provide dust-tight and water-resistant protection for one connector. The housing delivers an IP65-rated enclosure that shields electrical and data connections from dust ingress and low-pressure water jets, making it suitable for industrial and outdoor environments where robust protection is required.

Advantages

The single-piece design simplifies installation and reduces the number of parts required for reliable sealing. Constructed to meet IP65 protection, the hood minimizes maintenance needs by preventing contaminants from reaching connector contacts. Its compact form factor preserves connector accessibility while maintaining a secure enclosure against environmental factors.

Key specifications

• Protection rating: IP65 (dust-tight and protected against low-pressure water jets)
• Configuration: single-piece hood for one connector
• Application: protective enclosure for electrical and data connectors
• Installation: designed for straightforward mounting and sealing of one connector interface

How to use

Position the single-piece protective hood over the connector so that the connector interface aligns with the hood opening. Secure the hood according to the connector and panel mounting method specified by the connector system in use, ensuring the sealing surfaces are clean and correctly seated to achieve the IP65 rating. Verify that cable routing does not compromise the seal and that any fastening hardware is tightened to the required torque for a secure fit.

Recommendations

For reliable protection, use the hood in combination with compatible Harting connector inserts and mounting accessories; regularly inspect the sealing surfaces for wear or contamination and replace the hood if physical damage or persistent leaks are observed.
