Handheld bar code reader Newland HR52 Bonito 1D/2D CMOS Black

The Newland HR52 Bonito Corded is a handheld barcode reader designed for fast, accurate scanning of both 1D and 2D codes. Equipped with a megapixel CMOS sensor and wired USB connectivity with a 3 m coiled cable, it handles damaged, creased or cellophane-covered barcodes and additionally supports DotCode used on tobacco products. The scanner is compact and robust, with drop resistance up to 1.8 m and an IP54-level protection suitable for retail and stockroom environments.

Advantages

The HR52 Bonito Corded delivers one of the quickest and most accurate scan performances available thanks to its megapixel sensor and Newland Acuscan aiming technology. It reads virtually all common 1D and 2D symbologies, including QR, Data Matrix, PDF417 and DotCode. Soft white illumination and a cross laser aimer provide precise point-and-shoot targeting, and the supplied smart stand enables hands-free scanning while keeping the device ready for use. Built for everyday use, the device offers robust drop resistance and ESD protection.

Suitable for

• Retail point-of-sale scanning
• Stockroom and warehouse inventory tasks
• Scanning damaged or covered barcodes (cellophane, creases)
• Tobacco product coding with DotCode

Key specifications

• Scanner type: 1D/2D
• Sensor type: Megapixel CMOS
• Connectivity: Wired USB (3 m coiled cable)
• Supported 1D codes: EAN-13, UPC-E, UPC-A, Code 39, Code 128, GS1 DataBar, etc.
• Supported 2D codes: QR Code, Data Matrix, PDF417, Aztec Code, MaxiCode
• DotCode: Supported (retail/tobacco)
• Weight: 0.18 kg
• Drop resistance: 1.8 m
• Colour: Black

How to use

Connect the HR52 Bonito Corded to a POS terminal or PC via the USB cable. For handheld operation, aim the cross laser at the target barcode and press the trigger; the soft white illumination and Acuscan aimer help ensure accurate capture on the first press. For hands-free scanning, place the scanner in the smart stand and set the stand to the desired angle (vertical or horizontal) to suit the work surface. The scanner is powered via USB and requires no separate battery charging when used in the stand.

Recommendations

Use the smart stand for continuous scanning at POS to improve throughput and switch to handheld mode for aisle or stockroom scanning. Clean the optical window periodically to maintain reading performance, and avoid subjecting the scanner to impacts beyond its 1.8 m drop resistance.
