Graphics tablet Huion Kamvas Studio 16 KS1601 15.8 inch Quad HD IPS display 2560×1440, 16 GB RAM, 512 GB SSD, Wi‑Fi 6, battery 58 Wh

Huion Kamvas Studio 16 KS1601 is a standalone graphics tablet with a 15.8" Quad HD (2560×1440) fully laminated IPS touchscreen. It integrates an Intel i7-1165G7 processor with Intel Iris Xe graphics, 16 GB DDR4 RAM and a 512 GB SSD, and runs Windows 11 Pro. The device includes a battery (58 Wh) and supports wired and wireless connectivity via USB Type-C, Wi‑Fi 6 and Bluetooth 5.0. The display offers 400 cd/m² brightness, 100% Adobe RGB coverage and wide 178° viewing angles. A battery-free pen with 8192 pressure levels and 5080 lpi resolution is included, and the tablet features a built-in adjustable stand, front and rear cameras, fingerprint reader and other sensors.

Advantages

The tablet combines a high-resolution Quad HD fully laminated IPS touchscreen with accurate colour coverage (100% Adobe RGB) and a responsive battery-free pen supporting 8192 pressure levels, making it suitable for precise digital art and photo work. Its integrated Intel i7 processor and 16 GB RAM provide sufficient performance for on-device editing and creative applications, while Wi‑Fi 6 and Bluetooth 5.0 ensure modern connectivity. The included 58 Wh battery and 65 W charging allow mobile use with up to approximately 6 hours of runtime and around 2 hours to full charge.

Suitable for

• Digital painting and illustration
• Photo editing and retouching
• Graphic design and layout work
• On-the-go mobile studio and presentations

Key specifications

• Display: 15.8" (40.13 cm) IPS touchscreen, 2560×1440 (Quad HD), full lamination, 400 cd/m² brightness, 16.7 M colours, 1200:1 contrast, 178° viewing angles
• Processor: Intel i7-1165G7, 4 cores / 8 threads
• Graphics: Integrated Intel Iris Xe Graphics
• Memory & storage: 16 GB DDR4 RAM, 512 GB SSD
• Battery & power: 58 Wh battery, up to ~6 h runtime, 65 W charging, input 100–240 V, output voltages up to 20 V
• Connectivity: USB Type-C, Wi‑Fi 6 (802.11ax), Bluetooth 5.0
• Camera: Front 5 MP, Rear 8 MP
• Pen: Battery-free electromagnetic resonance technology, 8192 pressure levels, 5080 lpi resolution, 300 PPS report rate
• Physical: Working area 349.6×196.7 mm, dimensions approx. 384×234×11.9 mm, weight approx. 1.7 kg
• Sensors & extras: Fingerprint reader, accelerometer, hall sensor, built-in speakers and dual microphones

How to use

Unpack the tablet and connect the included USB Type-C cable to a power source to charge the internal battery. Power on the device to use the preinstalled Windows 11 Pro and follow the on-screen setup. Use the included battery-free pen directly on the fully laminated IPS touchscreen within the working area; pen input is detected up to a 1 cm maximum reading height. Adjust the integrated stand to a comfortable drawing angle. Install or run creative applications as needed and use Wi‑Fi or Bluetooth to connect to networks and peripherals.

Recommendations

For optimal colour-critical work, calibrate the display with a hardware calibrator and use applications that support wide colour spaces. Keep the screen and pen tips clean; replace pen tips from the supplied set as they wear. Charge the tablet regularly and avoid exposing it to temperatures outside 0–40 °C during operation.
