Freestanding signage display mount VISION VFM-W8X6T for 47 inch–90 inch screens, 130 kg capacity, VESA 300x300–800x600, Black

The VISION VFM-W8X6T is a heavy-duty freestanding signage display mount for flat-panel LCD and LED screens from 47" to 90". It supports VESA mounting patterns from 300×300 mm up to 800×600 mm and is rated for displays up to 130 kg. The slim black design holds the display approximately 51 mm from the wall and includes all necessary mounting bolts for straightforward installation.

Advantages

The mount uses heavy-gauge steel construction to provide a safe working load up to 130 kg, offering stability for large interactive panels and signage. Slotted holes on the wall plate allow post-fix levelling, and a secure latch engages the display when hung, with removable pull-rods for a concealed finish. The design supports optional accessories such as a flip-up laptop shelf and a central video-conference shelf, and provides VESA 100×100 mm fixing points to hide a media player behind the display.

Suitable for

Key specifications

How to use

Attach the supplied vertical arms to the display using the appropriate M5, M6 or M8 bolts provided, then fix the wall section to a suitable wall surface using appropriate anchors (not supplied). Use the slotted holes on the wall section to level the mount before final tightening. Hang the display on the horizontal section so the latch engages, and trim the plastic pull-rods so they sit hidden behind the screen. Fit optional shelves or media players to the provided VESA 100×100 mm fixing points if required.

Recommendations

Ensure the mounting surface and fixings are rated to support the combined weight of the mount and display. For dual-display or wide installations, join the horizontal sections side by side and verify load distribution. Curved screens are not supported by this mount.
