Flush-mounted distribution board Hager HAGE-VU48AT 4-row 48 modules IP20

The Hager flush-mounted distribution board HAGE-VU48AT is a recessed enclosure designed to accommodate up to 48 DIN-modules across four rows. It provides a neat, concealed solution for organizing circuit breakers, residual current devices and other DIN-rail mounted equipment in residential and light commercial electrical installations. The enclosure is intended for indoor use and offers IP20 protection against access to live parts and solid objects greater than 12 mm.

Advantages

This 4-row distribution board supports a tidy modular arrangement of protection and control devices, simplifying wiring and future expansion. The flush-mounted design enables a concealed installation that integrates with wall finishes while keeping the distribution elements accessible via the front. Constructed for standard DIN-rail components, the board streamlines component replacement and circuit labeling during installation and maintenance.

Suitable for

Key specifications

How to use

Select an appropriate wall location and prepare a recessed cavity sized to the enclosure. Secure the distribution board into the recess using the manufacturer-recommended fixings, ensuring it is level and flush with the finished wall surface. Fit DIN-rail mounted devices into the required positions, connect incoming supply and outgoing circuits according to applicable wiring standards and local regulations, and label each circuit for easy identification. Ensure the cover or door is fitted after installation and that protective seals and earthing connections are in place before energizing the board.

Recommendations

Install and commission the distribution board in accordance with local electrical codes and with a qualified electrician. Maintain access clearance in front of the panel and avoid environments with excessive humidity, dust or direct water exposure since the IP20 rating is intended for indoor dry locations.
