Floodlight Brennenstuhl 1178900100 Black LED IP44 IP54 Battery PIR Sensor

The Brennenstuhl 1178900100 LED wall light with motion sensor is a battery-powered outdoor/indoor spotlight in a black plastic housing. It combines an LED module with a PIR sensor for contactless activation and is protected against splashing water (IP44) with an LED assembly rated IP54. Compact dimensions (115 × 200 × 120 mm) and an adjustable head make it suitable for flexible wall mounting without fixed cabling. The lamp includes three LR14 (C) batteries and delivers a cool white light at 5000 K with a luminous flux of 440 lm.

Advantages

The product offers eight high-quality brand LEDs for consistent illumination and a PIR motion sensor with a 180° detection angle and up to 10 m range for reliable presence detection. The lighting head can be tilted and swiveled to direct light where needed. The duty cycle is adjustable up to 30 seconds and the battery life is long under typical intermittent use (approximately 800 days at six activations of 10 seconds per day).

Suitable for

• Outdoor façade and entrance lighting
• Garage, porch or balcony illumination
• Indoor corridors, staircases and utility rooms without mains wiring

Key specifications

• Brand: Brennenstuhl, MPN: 1178900100, EAN: 4007123671533
• Protection class: IP44 (housing) / IP54 (LED assembly)
• LEDs: 8 brand LEDs, luminous flux 440 lm, colour temperature 5000 K
• Motion sensor: PIR, 180° detection angle, range up to 10 m
• Adjustable timeout: up to 30 s
• Power supply: 3 × LR14 (C) batteries (included)
• Dimensions (W × D × H): 115 × 200 × 120 mm

How to use

Mount the floodlight on a vertical surface using appropriate screws and plugs for the mounting substrate. Insert the supplied 3× LR14 (C) batteries and set the desired timeout. Aim the tilt-and-swivel head toward the area to be illuminated. The PIR sensor will automatically switch the LED light on when motion is detected within the 180°/10 m detection zone and switch it off after the selected timeout.

Recommendations

For longest battery life, position the sensor to avoid frequent triggers from distant sources (e.g., busy sidewalks) and use the shortest timeout that meets your needs. For permanent illumination, consider mains-powered alternatives.
