Extralink PREDATOR V2 EPON OLT 1U 19'' 8X GIGABIT PON PORTS 4x 10G SFP+ UPLINK PORTS

The Extralink PREDATOR V2 EPON OLT is a 1U 19" rack-mountable optical line terminal designed for fiber access networks. It provides eight Gigabit EPON PON ports for subscriber connections, four 10G SFP+ uplink ports for high-capacity aggregation, and four 1G copper ports for local connectivity. The unit supports L2/L3 switching functions and a broad set of IEEE networking standards to integrate into existing infrastructures. With an AC input voltage of 230V and a compact 1U form factor, the PREDATOR V2 is built for efficient deployment in telecommunication racks and managed network rooms.

Advantages

The device combines multiple interface types — EPON SFP ports, 10G SFP+ uplinks and 1G copper ports — to enable flexible network topologies and smooth handoff between access and aggregation layers. Support for common IEEE standards and L2/L3 features ensures interoperability with standard Ethernet equipment and simplified management. Its 1U rack profile and standardized connectors make it straightforward to mount in telecom cabinets while dual redundant power supply options enhance operational reliability.

Suitable for

• Fiber-to-the-premises (FTTP) and EPON access networks
• Small to medium ISP aggregation and edge deployments
• Triple-Play services including voice, video and data
• Enterprise LAN edge connecting IP cameras, IoT devices and user workstations
• Telecommunication racks requiring compact 1U OLTs

Key specifications

• Form factor: 1U, 19" rack-mount
• PON interfaces: 8 Gigabit EPON SFP ports
• Uplink interfaces: 4 × 10G SFP+ ports
• Copper ports: 4 × 1G Ethernet ports
• Management ports: CONSOLE port and 1G Ethernet management port
• Switching capabilities: L2/L3 switching functions
• Supported networking standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ah, IEEE 802.1Q, 802.1p, 802.1w, 802.1x, 802.1D
• Power: AC input 230V; dual redundant power supply support
• Physical dimensions: 442 mm (length) × 315 mm (width) × 44 mm (height)

How to use

Install the Extralink PREDATOR V2 into a standard 19" rack using the 1U mounting space and secure appropriate airflow and cooling. Populate the EPON SFP slots with compatible EPON optical modules to connect subscriber ONUs/ONTs, and attach aggregation links to the 10G SFP+ uplinks toward the core network or aggregation switch. Use the provided CONSOLE or the 1G management port to access the device CLI or management interface for initial configuration, VLANs, QoS and L2/L3 settings. Ensure the AC 230V power input is connected to a properly rated power source and configure redundancy if a secondary power module is installed.

Recommendations

Deploy in temperature-controlled rack cabinets with stable AC supply and proper grounding. Use vendor-recommended EPON SFP modules and verify compatibility with subscriber ONUs/ONTs to ensure stable EPON links. For networks delivering Triple-Play or IP camera streams, configure VLANs and QoS to separate traffic types and prioritize latency-sensitive services. Regularly verify firmware updates and monitor redundant power status to maintain uninterrupted operation.
