Exsys EX-12003 USB 3.2 Gen 2x2 Type-C PCIe 3.0 x2 Adapter Card

The Exsys EX-12003 is a high-performance USB adapter card that adds one USB 3.2 Gen 2x2 Type-C port to your desktop computer via a PCIe 3.0 x2 slot. With data transfer speeds up to 20 Gbps, it is ideal for connecting high-speed external storage, docking stations, and other USB-C peripherals. The card features the ASMedia ASM3242 chipset and includes both standard and low-profile brackets for flexible installation.

Advantages

Experience ultra-fast data transfers up to 20 Gbps, backward compatible with USB 3.1 and USB 2.0 devices. The optional SATA power connector ensures stable power delivery for demanding devices. UASP support enhances performance with compatible drives, and hot-swap capability allows easy connection and disconnection without rebooting.

Suitable for

• Desktop computers requiring high-speed USB-C connectivity
• External SSDs, NVMe enclosures, and high-capacity storage
• USB-C docking stations and monitors
• Video capture devices and VR headsets

Key specifications

• Host Interface: PCIe 3.0 x2
• External Ports: 1 x USB 3.2 Gen 2x2 Type-C
• Data Transfer Rate: Up to 20 Gbps
• USB Standard: USB 3.2 Gen 2x2
• Backward Compatibility: USB 3.1 Gen 2 (10 Gbps), USB 3.1 Gen 1 (5 Gbps), USB 2.0 (480 Mbps)
• Chipset: ASMedia ASM3242
• Power Connector: Optional 15-pin SATA power connector
• Form Factor: Standard profile (low-profile bracket included)
• Operating System Support: Windows 10/11 (64-bit), Linux Kernel 5.x and above
• PCIe Lanes: 2
• UASP Support: Yes
• Hot-Swap Support: Yes
• Plug & Play: Yes (driver installation may be required for full functionality)
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, connect the optional SATA power cable when using high-power devices. Ensure your system has a free PCIe 3.0 x2 or higher slot. Compatible with Windows 10/11 64-bit and Linux Kernel 5.x and above.
