EVOLIGHTS LUMEN X V2 100W Moving Head Spot with 3-Facet Prism, 7-Color Wheel, Rotating Gobos, DMX512

Harness a 100W high-power white LED with a 15° beam angle, delivering razor-sharp aerial effects and intense mid-air projections. The LUMEN X V2 pairs a 3-facet rotating prism with dual gobo wheels and a 7-color dichroic wheel, giving lighting designers a compact yet feature-rich moving head for clubs, stages, and events.

Overview

The EVOLIGHTS LUMEN X V2 is a professional moving head spot engineered for dynamic beam shaping and pattern projection. Its 100W LED source produces a crisp 15° beam, while the motorized linear focus ensures sharp gobo and prism effects at any distance. With 540° pan and 270° tilt, the fixture covers a wide performance area, and 8/16-bit resolution guarantees smooth, precise movement.

What stands out

• 100W high-power white LED with 50,000-hour lifespan
• 3-facet rotating prism with bi-directional variable speed
• Rotating gobo wheel with 6 interchangeable gobos + open
• Static gobo wheel with 8 fixed gobos + open, including shake effect
• 7 dichroic colors + white, with half-color effect and variable rotation
• Motorized linear focus for sharp projections at any throw distance
• 16 DMX channels with LCD graphic display for easy configuration
• Multiple control modes: DMX512, Auto, Sound Active, Master/Slave

Technical details

• Light source: 100W high-power white LED, approx. 50,000 hours
• Beam angle: 15°
• Color wheel: 7 dichroic colors + white, half-color effect, variable speed rotation
• Static gobo wheel: 8 fixed gobos + open, gobo shake effect
• Rotating gobo wheel: 6 interchangeable rotating gobos + open, gobo rotation, gobo shake
• Prism: 3-facet rotating prism, bi-directional rotation with variable speed
• Focus: Motorized linear focus
• Dimmer: 0-100% linear electronic dimmer
• Strobe: 1-25 Hz, variable speed
• Pan movement: 540° (8/16 bit resolution)
• Tilt movement: 270° (8/16 bit resolution)
• Control modes: DMX512, Auto, Sound Active, Master/Slave
• DMX channels: 16
• Display: LCD graphic display
• Power consumption: 150W
• Input voltage: AC 100-240V, 50/60Hz
• Power connector: PowerCon In
• DMX connectors: 3-pin XLR In/Out
• Cooling system: Forced air cooling system

Our verdict

The LUMEN X V2 delivers professional-grade features in a compact package, making it an excellent choice for mobile entertainers and permanent installations alike.
