ERNITEC waterproof outdoor junction box model 0070-24143-WATERPROOF-L

ERNITEC 0070-24143-WATERPROOF-L is a waterproof outdoor junction box designed to protect electrical and low-voltage connections from moisture and weather. The enclosure provides a secure housing for cable joints and terminal blocks in external installations and is intended for use with surveillance, lighting and general outdoor electrical applications where protection against water ingress and mechanical impact at the front is required.

Advantages

The junction box features front-side waterproofing rated to IP67 while the connecting side at the back is protected to IP22, enabling safe placement of connections in exposed locations when the front faces the environment. The front surface has IK10-rated impact resistance for enhanced vandal protection. The metal chassis design offers anti-static and anti-interference characteristics that help maintain signal integrity for connected devices. The enclosure is compatible with continuous-operation installations and is suitable for integration with CCTV and outdoor monitoring equipment.

Suitable for

• Protecting cable splices and terminal blocks in outdoor CCTV and surveillance systems
• Housing connections for outdoor lighting circuits and low-voltage power runs
• Enclosing junctions at building facades, under canopies, or other semi-exposed locations
• Installations requiring front-side weatherproofing and vandal resistance

Key specifications

• Front ingress protection: IP67
• Rear/connecting-side ingress protection: IP22
• Front impact resistance: IK10
• Material: metal chassis with protective enclosure
• Designed for CCTV and outdoor monitoring applications
• VESA-compatible mounting: 400 × 200 (for integrated monitor or mounting interfaces)
• Suitable for continuous operation environments (24/7 usage compatible)

How to use

Select a mounting location where the junction box front faces the exposed environment while the cable entry is sheltered if possible to take advantage of the differing IP ratings. Open the enclosure and place cable splices or terminal blocks on the internal mounting points, making sure all connections are secure and insulated. Route cables through the designated gland or entry points and tighten seals to restore the IP67-rated front protection. Fasten the enclosure to the mounting surface using compatible hardware and VESA 400×200 mounting points when integrating with monitors or mounting brackets. Follow local electrical codes and standard safety procedures when making and sealing connections.

Recommendations

Use the junction box in installations where the front face is exposed to weather but the connector side can be positioned with some protection; periodically inspect seals and gaskets for wear, and ensure cable glands are properly tightened to maintain IP67 protection. For integration with CCTV monitors or displays, verify mechanical compatibility with the listed VESA size and the environmental ratings of attached devices.
