Epson CG19 EPPI Inductive Speed Sensor Pickup Assembly, M18 Thread, IP67, 2-Wire

Engineered for precision speed sensing in demanding hydraulic systems, the Epson CG19 EPPI Pickup Assembly delivers a passive inductive signal with a robust M18 stainless steel body and IP67 protection. This self-generating sensor requires no external power for basic signal output, making it a reliable choice for monitoring rotational speed on motors, pumps, and transmissions.

Overview

The CG19 EPPI is a factory-matched pickup assembly designed for Danfoss H1 and Series 45 hydraulic components. Its 2-wire frequency output ensures straightforward integration into existing control systems, while the 35 mm thread length and M18 x 1.5 mounting thread allow secure installation in standard ports. The sensor operates across a wide temperature range from -40 °C to +125 °C, ensuring consistent performance in extreme environments.

What stands out

• Passive inductive sensing for ferrous targets – no external excitation needed
• Stainless steel housing with IP67 rating for harsh industrial use
• 2-pin Deutsch-compatible connector for quick, reliable wiring
• Typical air gap of 0.5–2 mm for flexible mounting tolerance
• Direct compatibility with Danfoss hydraulic motors and pumps

Technical details

• Sensor type: Inductive speed sensor
• Detection principle: Passive inductive
• Target material: Ferrous metals
• Output signal: Frequency (AC voltage)
• Number of wires: 2
• Mounting thread: M18 x 1.5 mm
• Thread length: 35 mm
• Operating temperature: -40 to +125 °C
• Ingress protection: IP67
• Body material: Stainless steel
• Electrical connection: 2-pin connector (Deutsch DT04-2P compatible)
• Application: Speed sensing for hydraulic motors, pumps, transmissions
• Compatibility: Danfoss H1, Series 45, and other hydraulic components
• Air gap (typical): 0.5–2 mm
• Manufacturer series: CG19 EPPI
• Signal generation: Self-generating (no external power required for basic signal)

Our verdict

For maintenance teams and OEMs needing a dependable speed pickup for Danfoss hydraulic systems, the Epson CG19 EPPI offers a perfect balance of rugged construction, easy installation, and proven compatibility. Its passive design reduces complexity and failure points, making it a smart long-term investment.
