EPRADO-R19-9U/600-BLUE 9U Wall Mount Rack Cabinet 19-inch 600mm Blue

The EPRADO-R19-9U/600-BLUE is a high-quality 9U wall-mount rack cabinet designed for secure and organized mounting of 19-inch network and IT equipment. Constructed from cold-rolled steel with a durable blue finish, this enclosure offers reliable protection and easy access for your valuable hardware.

Advantages

This wall-mount rack cabinet provides a space-saving solution for small to medium-sized installations. Its lockable tempered glass front door and removable side panels ensure security while allowing convenient maintenance. The adjustable front and rear mounting rails accommodate various equipment depths, and the top and bottom cable entry points with brush strips keep cabling tidy.

Suitable for

• Network switches, patch panels, and routers
• Small server installations in offices or retail spaces
• Audio/visual equipment mounting
• Telecommunications and data distribution points

Key specifications

• Rack Standard: 19-inch
• Rack Units: 9U
• Mounting Type: Wall-Mount
• External Dimensions (WxDxH): 600 x 450 x 467 mm
• Internal Usable Depth: Approximately 400 mm
• Material: Cold Rolled Steel
• Front Door: Tempered Glass, Lockable
• Side Panels: Removable, Lockable
• Cable Entry: Top and Bottom with Brush Strips
• Ventilation: Passive with Fan Cutouts
• Color: Blue
• Static Load Capacity: 60 kg
• Protection Rating: IP20
• Assembly: Pre-assembled
• Compliance: CE, RoHS

Recommendations

For optimal performance, ensure the wall mount is securely fastened to a solid wall capable of supporting the total weight of the cabinet and installed equipment. Use cable management accessories to maintain airflow and organization.
