Enclosure Harting Han M BG 24B 09370240301 IP65

Harting Han M BG 24B enclosure provides a robust IP65-rated housing for Han M series rectangular connectors. Designed to protect connector inserts from dust and low-pressure water jets, this enclosure suits industrial control cabinets, machinery interfaces and field-mounted electrical junctions. The compact form accommodates a 24-pin configuration and matches the mechanical dimensions of Han M rectangular connector modules, enabling secure mounting and straightforward access for wiring and maintenance.

Advantages

The enclosure delivers environmental protection to IP65 standards, preventing dust ingress and resisting water jets while maintaining mechanical stability for connector inserts. Its design facilitates quick installation on panels or machinery surfaces and simplifies connector replacement without extensive disassembly. The material and sealing elements are chosen for durability in industrial settings and for maintaining contact integrity under vibration and moderate mechanical stress.

Suitable for

• Industrial control cabinets and panels
• Machine tool and automation interfaces
• Field junctions and outdoor electrical enclosures with weather exposure
• Signal and power connections in manufacturing environments

Key specifications

• Ingress protection rating: IP65 (dust-tight and protected against water jets)
• Compatible connector series: Han M rectangular connectors
• Configuration: 24-position accommodation
• Mounting: panel or surface mounting for machinery and cabinets
• Construction: durable industrial-grade housing with sealing gasket

How to use

Fit the enclosure to the panel or machine surface using the intended cut-out and mounting points, ensuring the sealing gasket is properly seated. Insert the Han M connector module into the enclosure and secure it according to the connector system’s locking method. Route and terminate cables to the connector contacts before closing the housing; verify that the gasket compresses evenly to maintain the IP65 seal. After installation, check mechanical retention and integrity of the seal periodically, especially after maintenance or exposure to harsh conditions.

Recommendations

Choose compatible Han M connector inserts rated for the required current and signal types; ensure cable glands or conduit entries used in the installation maintain the overall IP65 protection. Inspect the gasket and housing for damage during routine maintenance and replace sealing elements if wear or deformation is detected to preserve environmental protection.
