Enclosure frame Rittal SZ 2364.000 depth 699 mm, outer case gross weight 700 g

Rittal SZ 2364.000 is an enclosure frame designed for modular electrical cabinets and control panels with a depth of 699 mm. The frame provides the structural outline for mounting internal components and integrating with compatible cabinet systems. Its lightweight outer case construction supports applications where a reduced enclosure mass is beneficial while maintaining compatibility with Rittal mounting and assembly standards.

Advantages

The enclosure frame offers a specified depth of 699 mm that helps ensure consistent internal spacing for equipment and wiring. Its lightweight outer case reduces overall cabinet weight, simplifying handling and installation. The frame is manufactured to fit with Rittal cabinet components, enabling straightforward integration and standardised assembly procedures.

Suitable for

Key specifications

How to use

Install the enclosure frame as part of the cabinet assembly according to Rittal installation guidelines and the cabinet model’s mounting points. Ensure the frame is correctly aligned and secured before fitting internal components such as mounting plates, DIN rails, or equipment racks. Verify clearances for wiring and ventilation based on installed components and electrical standards applicable to your installation.

Recommendations

For safe and reliable operation, handle the frame with appropriate lifting methods and verify compatibility with the target cabinet model. Follow applicable national electrical and mechanical installation codes and use recommended fasteners and seals when integrating the frame into a complete enclosure.
