ELED-173S-GR 10W LED Ceiling Light with PIR Motion Sensor, 850lm, 4000K, IP44

The ELED-173S-GR is a modern 10W integrated LED ceiling light featuring a built-in PIR motion sensor for automatic lighting control. Designed for indoor and covered outdoor use (IP44 splash-proof), it delivers 850 lumens of natural white light at 4000K, making it ideal for hallways, staircases, corridors, bathrooms, and utility rooms. The sensor offers 360° detection with an adjustable range of 3-6 meters, time delay from 10 seconds to 5 minutes, and lux threshold from <10 to 2000 lux, ensuring energy-efficient operation.

Advantages

Energy-saving LED technology with 30,000-hour lifespan and A+ energy class. The integrated PIR sensor eliminates the need for separate switches and reduces electricity waste by automatically turning off when no motion is detected. Easy surface mount installation on ceilings. Splash-proof design (IP44) provides protection against water splashes, suitable for bathrooms and covered outdoor areas.

Suitable for

• Indoor hallways, corridors, staircases
• Bathrooms, toilets, utility rooms
• Covered outdoor areas (e.g., porches, balconies)
• Garages, basements, storage rooms
• Offices, meeting rooms, break rooms

Key specifications

• Power: 10W (integrated LED)
• Luminous flux: 850 lumens
• Color temperature: 4000K (natural white)
• Color rendering index (CRI): >80 Ra
• Beam angle: 120°
• Sensor: PIR motion sensor, 360° detection, 3-6m range
• Adjustable time delay: 10s - 5min
• Adjustable lux threshold: <10 - 2000 lux
• Input voltage: AC 220-240V, 50/60Hz
• IP rating: IP44 (splash-proof)
• Material: PC diffuser, metal base
• Mounting: surface mount (ceiling)
• Dimensions: diameter 173mm, height 65mm
• Weight: 0.3 kg
• Lifespan: 30,000 hours
• Energy efficiency class: A+
• Operating temperature: -20°C to +40°C
• Certifications: CE, RoHS

Recommendations

For optimal sensor performance, mount the light at a height of 2.5-4 meters and avoid placing near heat sources or air vents. Suitable for indoor use and covered outdoor areas where the light is not directly exposed to rain. Not dimmable.
