Electrical enclosure Rittal 9523.000 — polyamide/polycarbonate IP66, 360×254×111 mm

Rittal 9523.000 is a compact electrical enclosure combining a fibre-glass reinforced polyamide housing with a polycarbonate cover. With external dimensions of 360 × 254 × 111 mm and an IP66 rating, the enclosure provides protection against dust ingress and powerful water jets, making it suitable for industrial and outdoor installations where reliable environmental protection for electrical components and small control units is required.

Advantages

The enclosure features a robust polyamide housing reinforced with fibre glass for enhanced mechanical strength and a polycarbonate cover available in grey or transparent options to suit visibility needs. The IP66 protection class ensures resistance to dust and powerful water jets. Its compact footprint and durable materials offer long-term performance in demanding environments while allowing easy visual inspection when a transparent cover is chosen.

Suitable for

Key specifications

How to use

Mount the enclosure on a stable surface or panel using appropriate fasteners and ensure correct orientation for cable entry. Open the polycarbonate cover to install terminal blocks, controllers or wiring harnesses on the internal mounting surface. Use suitable grommets, cable glands or conduit entries at designated entry points to maintain the IP66 rating. Close and secure the cover to restore environmental protection; if a transparent cover is used, visual checks can be performed without opening the enclosure.

Recommendations

Choose the transparent cover when frequent visual inspection of indicators or displays is required; select the grey cover when additional light rejection or a uniform appearance is preferred. For maintained IP66 performance, install appropriate cable glands and avoid modifying the enclosure without using compatible sealing accessories.
