DIN‑mount dual relay module Shelly 2L Gen3, 2 channels, Wi‑Fi/Bluetooth, 220–240V AC, 50Hz, plastic housing

Shelly 2L Gen3 is a DIN‑mount dual relay module with two independently controlled channels for switching appliances on 220–240 V AC (50 Hz). It supports Wi‑Fi (802.11 b/g/n) and Bluetooth connectivity, programmable scripts and webhooks, intelligent on/off control, sunrise/sunset scheduling and built‑in overheat protection. The module comes in a compact plastic housing with dimensions 42×37×16 mm and low power consumption (max 1.2 W), suitable for installation on DIN rails in electrical cabinets for lighting or home automation tasks.

Advantages

The device offers two separate channels for independent control of loads, remote operation via Wi‑Fi and Bluetooth, and support for automation through scripts and webhooks. Intelligent on/off logic with sunrise/sunset scheduling helps adapt switching to natural light cycles, while overheat protection increases operational safety. Its compact plastic housing and low standby power consumption make it convenient for space‑constrained DIN‑rail installations.

Suitable for

• Controlling lighting circuits in residential or small commercial electrical panels
• Switching household appliances and loads up to the relay rating
• Integrating into home automation systems using Wi‑Fi, Bluetooth, scripts or webhooks

Key specifications

• Number of channels: 2 (independently controlled relays)
• Supply voltage: 220–240 V AC, 50 Hz
• Wireless: Wi‑Fi (802.11 b/g/n) and Bluetooth
• Power consumption (max): 1.2 W
• Operating temperature range: -20 to 40 °C
• Operating relative humidity: 30–70%
• Housing material: Plastic
• Dimensions (W×H×D): 42 × 37 × 16 mm
• Weight: 28 g

How to use

Install the Shelly 2L Gen3 on a standard DIN rail inside an electrical cabinet, connect the AC supply (220–240 V AC, 50 Hz) and wire the loads to the two relay outputs according to local electrical codes. Configure network connectivity via Wi‑Fi or Bluetooth using the manufacturer app or web interface, then set up channels, scripts, webhooks or sunrise/sunset schedules as required. Verify relay operation and safety features after installation.

Recommendations

Use the module within the specified voltage, temperature and humidity ranges. Ensure connections and installation are performed by a qualified electrician and follow local regulations. Avoid exposing the device to direct moisture; use within an enclosed electrical panel for best protection.
