DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow

DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
DIGITUS installation cable - CAT 7 - S/FTP - AWG 23/1 simplex - 500m - yellow
R9,723
Future-oriented standards and high-end quality for your network.- 10GBit Ethernet- 1200 MHz transmission frequency- Permanent Link certified- PoE, PoE+, 4PPoE (IEEE 802.3af;3at;3bt)- BauPVO class B2ca (check the DoP for further classification)The Digitus Cat 7 installation cable is designed for use ... Read More
Stock 67 Code 328511 Brand DIGITUS Model DK-1745-VH-5 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Future-oriented standards and high-end quality for your network.

- 10GBit Ethernet
- 1200 MHz transmission frequency
- Permanent Link certified
- PoE, PoE+, 4PPoE (IEEE 802.3af;3at;3bt)
- BauPVO class B2ca (check the DoP for further classification)

The Digitus Cat 7 installation cable is designed for use in structured data centers and building cabling in accordance with ISO/IEC 11801, DIN EN 50288-4-1, DIN EN 50173, IEC 61156-7, EN 50288-9-1. The cable is ideal for the transmission of analog and digital data and supports PoE, PoE+, 4PPoE (IEEE 802.3af;3at;3bt). The shield structure consists of individually shielded pairs with a tinned copper braid, which ensures excellent shielding and electrical values.

Key Highlights
  • Physical properties:
  • Conductor: Bare copper wire, AWG 23/1
  • System(s) of assessment and verification of constancy of performance: System 3
  • Insulation: SFS-PE (foamed polyethylene jacket)
  • Total number of insulated conductors: 8, twisted into 4 pairs
  • Color code: Blue-white, orange-white, green-white, brown-white
  • Shielding of the individual pairs: aluminum-laminated polyester film, covers 100%
  • Overall shielding: copper braiding
  • Outer sheath: B2ca according to EN 50575; LSZH
  • Outer sheath thickness (nominal): 0.50 mm (Eca); 0.52 mm (Dca); 0.60 mm (Cca); 0.60 (B2ca)
  • Color: Orange (RAL 2008)
  • Mechanical properties:
  • Strain relief: 135N max.
  • Dynamic bending radius: 8x AD mm min.
  • Static bending radius: 4x AD mm min.
  • Transport and storage temperature range: -20 °C to +60 °C
  • Operating temperature range: -20 °C to +50 °C
  • Installation temperature range: 0 °C to +50 °C
  • Electrical properties:
  • Impedance: 100±15 Ohm @ 4 - 1000 MHz; 100±25 OHM @ 100-600 MHz
  • Capacitance: 45pF/m nom. at 1KHz
  • Capacitance: 40 pF/m nominal @ 1 KHz
  • Insulation resistance: 5 GOhm x km min.
  • DC resistance: 95 Ohm/km max. (2% max. unbalanced resistance)
  • Loop resistance: 190 Ohm/km max. (2% max. unbalanced resistance)
  • Operating voltage: 72 Vdc max.
  • Coupling attenuation: CA-Type 1b
  • Phase delay: 450 nS/100 m max.
  • Time delay: 10 nS/100 m max.
  • Separation class: "d" according to EN 50174-2
  • NVP: 79%
  • Flame spread: EN 60332-1-2 (LSOH-PVC)
  • Halogen-free, corrosiveness: EN 60754-1/2 (LSOH)
  • Smoke density EN 61034-2
Specifications
AWG wire size
23/1
Cable length
500 m
Cable shape
Round
Cable shielding
S/FTP (S-STP)
Cable standard
Cat7
Cabling technology
10GBase-T
Certification
CPR class B2ca
Conductor type
Solid
Connector 1
No
Connector 1 gender
No
Connector 2
No
Connector 2 gender
No
Country of origin
China
Ethernet interface type
10 Gigabit Ethernet
Frequency
1200 MHz
Impedance
100 O
Jacket material
Low smoke zero halogen (LSZH)
Operating temperature (T-T)
-20 - 50 °C
Product colour
Orange
Quantity per pack
1 pc(s)
Storage temperature (T-T)
-20 - 75 °C
UK Trade Tariff code
85444920

Leaflet

Open Leaflet
