DIGITUS installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey

DIGITUS installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey
DIGITUS installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey
DIGITUS installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey
DIGITUS installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey
R4,653
Future-oriented standards and high-end quality for your network.- 1GBit Ethernet- 100 MHz transmission frequency- PoE Power over Ethernet support- BauPVO Class EcaThe Digitus® Cat.5e F/UTP installation cable is characterized by the following cable structure 4x2x AWG24/1 and achieves a transmission f... Read More
Stock 121 Code 325051 Brand DIGITUS Model DK-1521-V-305 Warranty 2 Years

Shipping & Returns

Estimated delivery Friday, October 2
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Future-oriented standards and high-end quality for your network.

- 1GBit Ethernet
- 100 MHz transmission frequency
- PoE Power over Ethernet support
- BauPVO Class Eca

The Digitus® Cat.5e F/UTP installation cable is characterized by the following cable structure 4x2x AWG24/1 and achieves a transmission frequency of up to 100 MHz. The PVC cable sheath conforms to BauPVO Euroclass Eca. The cable is suitable for structured building cabling in secondary and tertiary areas. Conforms to the standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-2-1.

Key Highlights
  • Physical properties:
  • Conductor: Bare copper wire, AWG 24/1
  • System(s) of assessment and verification of constancy of performance: System 3
  • Insulation: PE (polyethylene)
  • Total number of insulated conductors: 8, twisted into 4 pairs
  • Color code: Blue-white, orange-white, green-white, brown-white
  • Shielding of the individual pairs: None
  • Overall shielding: foil shield, twin wire
  • Outer sheath: Eca according to EN 50575; PVC
  • Outer sheath thickness (nominal): 0.55 mm nominal
  • Outer casing color: Grey (RAL 7035)
  • Mechanical properties:
  • Strain relief: 150N max.
  • Dynamic bending radius: 8x AD mm min.
  • Static bending radius: 4x AD mm min.
  • Transport and storage temperature range: -20 °C to +75 °C
  • Operating temperature range: -20 °C to +60 °C
  • Installation temperature range: 0 °C to +50 °C
  • Outer diameter simplex (nominal): 6.1 mm nominal
  • Electrical properties:
  • Impedance: 100±5 Ohm @ 1-100 MHz
  • Capacitance: 40 pF/m nominal @ 800 Hz
  • Capacitance unbalance (pair-earth): 1.5 pF/m max. @ 1 KHz
  • Insulation resistance: 5 GOhm x km min.
  • Loop resistance: 147 Ohm/km max. (2% max. unbalanced resistance)
  • Operating voltage: 72 Vdc max.
  • Coupling attenuation: CA-Type 3
  • Phase delay: 535 nS/100 m max.
  • Time delay: 20 nS/100 m max.
  • Isolation class: "b" according to EN 50174-2
  • NVP: 69%
Specifications
AWG wire size
24/1
Cable class
D
Cable length
305 m
Cable shielding
F/UTP (FTP)
Cable standard
Cat5e
Cabling technology
10/100/1000Base-T(X)
Certification
CPR class Eca
Conductor type
Solid
Connector 1
No
Connector 2
No
Connector contacts plating
Gold
Country of origin
China
Harmonized System (HS) code
84733080
Jacket material
Polyvinyl chloride (PVC)
Package depth
210 mm
Package volume
35280 cm³
Package weight
13.5 kg
Package width
400 mm
Product colour
Grey
UK Trade Tariff code
85444920

Leaflet

Open Leaflet
