DIGITUS Ethernet cable - Cat 5e - U/UTP - AWG 24/1 - 305m - Grey

DIGITUS Ethernet cable - Cat 5e - U/UTP - AWG 24/1 - 305m - Grey
DIGITUS Ethernet cable - Cat 5e - U/UTP - AWG 24/1 - 305m - Grey
DIGITUS Ethernet cable - Cat 5e - U/UTP - AWG 24/1 - 305m - Grey
DIGITUS Ethernet cable - Cat 5e - U/UTP - AWG 24/1 - 305m - Grey
R2,876
Future-oriented standards and high-end quality for your network.- 1GBit Ethernet- 100 MHz transmission frequency- PoE Power over Ethernet support- BauPVO Class EcaThe Digitus Cat 5e U/UTP installation cable is suitable for use in structured data centers and building cabling in accordance with ISO/IE... Read More
Stock 1 Code 91749 Brand DIGITUS Model DK-1511-V-305-1 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Future-oriented standards and high-end quality for your network.

- 1GBit Ethernet
- 100 MHz transmission frequency
- PoE Power over Ethernet support
- BauPVO Class Eca

The Digitus Cat 5e U/UTP installation cable is suitable for use in structured data centers and building cabling in accordance with ISO/IEC 11801, DIN EN 50288-3-1, DIN EN 50173. The cable is excellent for the transmission of analog and digital data and supports POE. It offers reliable transmission quality for standard applications.

Key Highlights
  • Physical properties:
  • Conductor: Bare copper wire, AWG 24/1
  • Insulation: PE (polyethylene)
  • Total number of insulated conductors: 8, twisted into 4 pairs
  • Color code: Blue-white, orange-white, green-white, brown-white
  • Shielding of the individual pairs: None
  • Overall shielding: None
  • Outer sheath: Eca according to EN 50575; PVC
  • Outer sheath thickness (nominal): 0.50 mm nominal
  • Outer casing color: Grey (RAL 7035)
  • Mechanical properties:
  • Strain relief: 150N max.
  • Dynamic bending radius: 8x AD mm min.
  • Static bending radius: 4x AD mm min.
  • Transport and storage temperature range: -20 °C to +75 °C
  • Operating temperature range: -20 °C to +60 °C
  • Installation temperature range: 0 °C to +50 °C
  • Outer diameter simplex (nominal): 4.7 mm nominal
  • Electrical properties:
  • Impedance: 100±5 Ohm @ 1-600 MHz
  • Capacitance: 40 pF/m nominal @ 800 Hz
  • Capacitance unbalance (pair-earth): 1.5 pF/m max. @ 1 KHz
  • Insulation resistance: 5 GOhm x km min.
  • Loop resistance: 147 Ohm/km max. (2% max. unbalanced resistance)
  • Operating voltage: 72 Vdc max.
  • Coupling attenuation: CA-Type 3
  • Phase delay: 535 nS/100 m max.
  • Time delay: 20 nS/100 m max.
  • Isolation class: "b" according to EN 50174-2
  • NVP: 69%
Specifications
AWG wire size
24/1
Cable class
D
Cable length
305 m
Cable shielding
U/UTP (UTP)
Cable standard
Cat5e
Cabling technology
10/100/1000Base-T(X)
Certification
CPR class Eca
Conductor type
Solid
Connector 1
No
Connector 2
No
Country of origin
China
Frequency
100 MHz
Harmonized System (HS) code
84733080
Input impedance
100 O
Jacket material
Polyvinyl chloride (PVC)
Networking standards
IEEE 802.3, IEEE 802.5
Operating temperature (T-T)
-20 - 60 °C
Package depth
350 mm
Package volume
24500 cm³
Package weight
9.12 kg
Package width
350 mm
Product colour
Grey
Quantity per pack
1 pc(s)
Storage temperature (T-T)
-20 - 75 °C
UK Trade Tariff code
85444920

Leaflet

Open Leaflet
