DIGITUS CAT 8.1 S-FTP Patch Cable, Cu, LSZH, 0.5 m, Grey

The DIGITUS CAT 8.1 S-FTP Patch Cable is a high-performance network cable designed for demanding data center and enterprise applications. With a bandwidth of up to 2000 MHz and data transfer rates of up to 40 Gbit/s, it supports 40GBase-T networks. The cable features S/FTP shielding (pairs in metal foil plus overall braid) for excellent protection against electromagnetic interference, ensuring reliable and fast data transmission. Made with copper conductors and a low smoke zero halogen (LSZH) jacket, it is safe for use in enclosed spaces. The 0.5 m length is ideal for short connections in server racks or patch panels.

Advantages

This patch cable offers superior performance and reliability for high-speed networks. The S/FTP shielding minimizes crosstalk and external interference, while the gold-plated connectors ensure optimal conductivity and corrosion resistance. The snagless molded boot protects the connector tabs during installation and removal. LSZH jacket reduces toxic smoke in case of fire, making it suitable for public and commercial buildings.

Suitable for

• Data centers and server rooms
• Enterprise networks requiring 40 Gbit/s speeds
• High-frequency trading and financial systems
• Video streaming and broadcasting
• Any environment where low smoke and halogen-free materials are required

Key specifications

• Cable Category: CAT 8.1
• Shielding: S/FTP (PIMF)
• Conductor Material: Copper (Cu)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Connector Type: RJ45 (8P8C) on both ends
• Connector Plating: Gold-plated (50µm)
• Length: 0.5 m
• Data Transfer Rate: Up to 40 Gbit/s
• Bandwidth: Up to 2000 MHz
• AWG: 26 AWG
• Wiring Standard: TIA/EIA 568B
• PoE Support: Yes (PoE, PoE+, 4PPoE)
• Colour: Grey
• Boot Type: Molded, Snagless
• Flame Retardancy: IEC 60332-1
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Operating Temperature: -20°C to +60°C

Recommendations

For optimal performance, use this cable with CAT 8.1 compatible network equipment. Ensure proper cable management to avoid sharp bends and maintain signal integrity.
