DIGITUS CAT 8.1 S/FTP Patch Cable, Cu, LSZH, 0.5 m, Grey

The DIGITUS CAT 8.1 S/FTP Patch Cable is a high-performance network cable designed for demanding data center and enterprise applications. With support for data transfer rates up to 40 Gbit/s and a bandwidth of 2000 MHz, this cable ensures reliable and fast connectivity for 40GBase-T networks. The S/FTP shielding provides excellent protection against electromagnetic interference, while the LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces.

Advantages

This patch cable offers superior performance and reliability. The gold-plated RJ45 connectors with 50µm plating ensure optimal signal transmission and corrosion resistance. The stranded conductor construction provides flexibility for easy installation in tight spaces. The cable is halogen-free and flame retardant, making it suitable for use in public buildings and areas with strict fire safety requirements.

Suitable for

• Data centers requiring high-speed 40GBase-T connections
• Enterprise networks demanding high bandwidth and low latency
• Installations where fire safety is critical (LSZH jacket)
• PoE applications including PoE, PoE+, and 4PPoE

Key specifications

• Cable Category: CAT 8.1
• Shielding: S/FTP (Screened Foiled Twisted Pair)
• Conductor Material: Copper (Cu)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Length: 0.5 m
• Colour: Grey
• Connector: RJ45 (8P8C) with gold-plated contacts (50µm)
• Data Transfer Rate: Up to 40 Gbit/s
• Bandwidth: Up to 2000 MHz
• AWG: 24 AWG
• Cable Construction: Stranded
• Wiring Standard: TIA/EIA 568B
• Halogen-Free: Yes
• Flame Retardant: Yes
• PoE Support: PoE, PoE+, 4PPoE (IEEE 802.3af/at/bt)
• Operating Temperature: -20°C to +60°C
• Outer Diameter: Approx. 7.5 mm
• Standards Compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2, IEEE 802.3bq

Recommendations

For optimal performance, pair this cable with compatible CAT 8.1 network equipment. Ensure proper cable management to maintain signal integrity.
