DIGITUS Cat.6A U/UTP B2ca AWG 23/1 LSOH 100m Blue Installation Cable

The DIGITUS Cat.6A U/UTP installation cable is a high-performance, unshielded twisted pair cable designed for reliable 10 Gigabit Ethernet (10GBase-T) networks. With a CPR classification of B2ca-s1a, d1, a1, it meets stringent fire safety requirements for building installations. The cable features solid bare copper conductors (AWG 23/1) and a low smoke zero halogen (LSOH) jacket, ensuring minimal toxic gas emission in case of fire. Ideal for structured cabling in commercial and industrial environments.

Advantages

This cable offers excellent transmission performance up to 500 MHz, supporting high-bandwidth applications. The LSOH jacket provides enhanced safety in public and residential buildings. The solid AWG 23/1 conductors ensure stable connections and long-term reliability. The cable is halogen-free and complies with international standards.

Suitable for

• 10 Gigabit Ethernet networks (10GBase-T)
• Structured cabling in offices, data centers, and industrial facilities
• Installations requiring CPR B2ca fire classification
• Environment where low smoke and zero halogen materials are required

Key specifications

• Cable Standard: Cat.6A (Class EA)
• Shielding: U/UTP (Unshielded Twisted Pair)
• Fire Performance (CPR): B2ca-s1a, d1, a1
• Conductor: AWG 23/1 Solid Bare Copper
• Number of Pairs: 4
• Jacket Material: LSOH (Low Smoke Zero Halogen)
• Jacket Color: Blue
• Length: 100 m
• Outer Diameter: Approx. 7.2 mm
• Frequency Range: Up to 500 MHz
• Impedance: 100 Ohm
• NVP: 79%
• Operating Temperature: -20°C to +60°C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2, IEC 60332-3-24
• Halogen Free: Yes
• Packaging: Cable Reel

Recommendations

For optimal performance, use with Cat.6A compatible connectors and patch panels. Ensure proper installation practices to maintain cable performance.
