Desktop/Server Memory PATRIOT DDR5 8 GB 5600 MT/s 288-pin UDIMM 1.1V On-Die ECC

Single 8 GB DDR5 memory module from PATRIOT designed for PC and server use. It operates at a data transfer rate of 5600 MT/s with a 1.1 V supply and includes On-Die ECC for improved data integrity. The module uses the 288-pin UDIMM form factor and measures 133 × 32 × 2 mm, weighing 17 g. Operating temperature range is 0–85 °C.

Advantages

The PATRIOT DDR5 8 GB module offers a high transfer rate suitable for modern systems and On-Die ECC to help detect and correct certain memory errors. Its low operating voltage (1.1 V) reduces power consumption compared with older standards, and the compact 288-pin UDIMM format ensures compatibility with desktop and many server motherboards.

Suitable for

• Desktop PC memory upgrades
• Server memory expansions in compatible systems
• Replacing faulty or lower-speed DDR5 modules
• Systems requiring On-Die ECC for improved data integrity

Key specifications

• Memory capacity: 8 GB
• Memory type: DDR5
• Data transfer rate: 5600 MT/s
• Memory voltage: 1.1 V
• On-Die ECC: Yes
• Form factor: 288-pin UDIMM
• Operating temperature: 0–85 °C
• Dimensions (W × H × D): 133 × 32 × 2 mm
• Weight: 17 g

How to use

Power down the computer and disconnect it from mains before installing the memory module. Open the case and locate a compatible 288-pin UDIMM slot on the motherboard. Align the module with the slot notch and press firmly and evenly until the retaining clips lock into place. Close the case, reconnect power, and boot the system; verify in the BIOS/UEFI or operating system that the new memory is recognized and operating at the correct speed.

Recommendations

Install modules in matched pairs or follow the motherboard manufacturers memory population guidelines for optimal performance. Ensure BIOS/UEFI is updated to the latest version to guarantee compatibility with DDR5 modules and to enable correct timing and voltage settings.
