DELTA OPTICAL R10-4U/280 Wall Mount Rack Cabinet 4U 10-inch Black

The DELTA OPTICAL R10-4U/280 is a robust wall-mount rack cabinet designed for 10-inch rack standards, offering 4U of space for networking and AV equipment. Its compact depth of 280 mm makes it ideal for shallow installations, while the lockable tempered glass door ensures security and visibility.

Advantages

This rack cabinet combines durability with ease of installation. The welded cold-rolled steel frame provides a sturdy structure, and the powder-coated finish (RAL 9004) resists corrosion. The reversible door opens 180 degrees for full access, and removable side panels simplify cable management. With a load capacity of up to 20 kg, it supports a variety of devices.

Suitable for

• Small network setups (switches, patch panels)
• Audio/video equipment in meeting rooms or retail spaces
• Security system components (DVRs, controllers)
• Wall-mounted server or IT equipment in offices

Key specifications

• Rack standard: 10-inch
• Rack units: 4U
• External dimensions (W x H x D): 310 x 230 x 280 mm
• Usable depth: approx. 240 mm
• Material: Cold-rolled steel, powder coated
• Door: Tempered glass, lockable, reversible, 180° opening
• Side panels: Removable, solid steel
• Cable entry: Top and bottom with knockouts/brush strips
• Ventilation: Passive with fan cutouts
• Mounting: Wall-mount
• Load capacity: 20 kg
• Protection rating: IP20
• Color: Black (RAL 9004)
• Included accessories: 2 keys, wall mounting kit, cage nuts and screws

Recommendations

For optimal performance, ensure the wall is capable of supporting the total weight of the cabinet and installed equipment. Use the included mounting kit for secure installation. This cabinet is best suited for indoor environments with controlled temperature and humidity.
