Delock Water Filter for Garden Irrigation with Stainless Steel Filter

In-line garden water filter with a 120-mesh stainless steel screen that captures particles down to 125 µm, protecting sprinklers, pumps, and drip systems from clogging. The transparent housing lets you check contamination at a glance, and the reusable filter element rinses clean in seconds.

Advantages

Stainless steel mesh delivers reliable filtration without disposable cartridges. The clear body shows exactly when cleaning is needed, and the 3/4" BSP threads fit standard garden fittings for quick installation. Rated for up to 6 bar pressure and 3000 l/h flow, it handles high-demand irrigation without starving downstream equipment.

Suitable for

• Garden irrigation lines and sprinkler systems
• Protecting pumps from sand and debris
• Rainwater harvesting and storage tanks
• Greenhouse and nursery watering setups
• Pre-filtering water for drip emitters and misters

Key specifications

• Filter type: in-line water filter
• Filter material: stainless steel mesh, 120 mesh / 125 µm
• Housing: transparent plastic
• Connection: male thread, 3/4 inch (DN20), BSP (G 3/4")
• Max. operating pressure: 6 bar (0.6 MPa)
• Max. operating temperature: 60 °C
• Max. flow rate: 3000 l/h (3 m³/h)
• Filter element: reusable and replaceable
• Installation orientation: horizontal or vertical

Recommendations

Install the filter upstream of any sensitive components, with the transparent bowl facing downward for easy inspection. Flush the mesh regularly during heavy sediment loads to maintain full flow. For hard-water areas, pair with a fine cartridge filter downstream if finer filtration is needed.
