DELOCK Pneumatic Hose 12 x 8 mm 50 m Roll White

In automated production lines and workshop compressed-air systems, a reliable hose is the silent link between compressor and tool. The DELOCK Pneumatic Hose 12 x 8 mm in a 50-meter roll ensures consistent flow and durable service for demanding pneumatic applications. Its white polyamide construction resists oils, greases, and many solvents, making it a versatile choice for industrial environments.

Key specifications

• Outer diameter: 12 mm
• Inner diameter: 8 mm
• Wall thickness: 2 mm
• Length: 50 m
• Material: Polyamide (PA)
• Colour: White
• Maximum operating pressure: 12 bar (1.2 MPa)
• Minimum burst pressure: 40 bar (4.0 MPa)
• Temperature range: -40°C to +80°C
• Hardness: Shore D 72
• Minimum bend radius: 60 mm
• Standards: DIN 73378, DIN EN ISO 7628

Why choose it

This hose offers a balanced combination of flexibility and rigidity (semi-rigid), allowing easy routing without kinking. Its UV resistance and chemical resistance make it suitable for outdoor and demanding indoor settings. With a burst pressure three times the operating pressure, it provides a safety margin for reliable continuous use.

Ideal use cases

• Pneumatic control systems and automation lines
• Instrumentation and measuring equipment
• Compressed air distribution in workshops and plants
• Fluid transfer for nitrogen, inert gases, water, and oils

Good to know

The 50-meter roll allows you to cut custom lengths for your installation, minimising waste. The white colour helps distinguish circuits and maintains a clean appearance. Compatible with standard push-in fittings for quick assembly. RoHS compliant and manufactured to DIN standards for quality assurance.
