DELOCK DIN Rail Terminal Block Set, 6-Pin, Screw Connection, Gray

This DELOCK terminal block set provides a reliable screw connection solution for DIN rail mounting, featuring a 6-pin configuration and twin connection blocks for efficient wiring.

Highlights

• 6 positions with screw connection technology
• Supports conductor cross-sections from 0.14 to 4 mm² (solid and flexible)
• Rated for 800 V and 24 A, suitable for demanding industrial applications
• Mounts on standard DIN rails (NS 35/7.5 and NS 35/15)
• Made of gray polyamide (PA) with UL 94 V0 flammability rating

In daily use

Installation is straightforward: strip 9 mm of insulation, insert the conductor, and tighten the M3 screw to a torque of 0.5–0.6 Nm. The twin connection blocks allow two conductors per position, simplifying wiring. The set includes 6x UT 2,5-TWIN-MT-P terminal blocks, 2x D-UT 2,5/10 end covers, and 1x ZB 6 marking strip.

Full specifications

• Product type: DIN rail terminal block set
• Number of positions: 6
• Connection technology: screw connection
• Conductor cross-section (solid): 0.14–4 mm²
• Conductor cross-section (flexible): 0.14–4 mm²
• Rated voltage (IEC): 800 V
• Rated current (IEC): 24 A
• Mounting type: DIN rail (NS 35/7.5, NS 35/15)
• Color: gray
• Insulation material: polyamide (PA)
• Flammability rating: UL 94 V0
• Operating temperature: -60 °C to 105 °C
• Stripping length: 9 mm
• Screw thread: M3
• Tightening torque: 0.5–0.6 Nm
• Number of connections per block: 3 (twin)
• Pollution degree: 3
• Overvoltage category: III
• Included components: 6x UT 2,5-TWIN-MT-P, 2x D-UT 2,5/10, 1x ZB 6 marking strip

Final note

A complete set for professional DIN rail terminal connections, offering high current capacity and robust construction.
