DELOCK DIN Rail Terminal Block Set 4-Pin with Screw Locking, 800 V, 32 A, Grey

This DELOCK terminal block set handles up to 800 V and 32 A, making it a robust choice for industrial control cabinets and distribution boards. The 4-pin push-in design with screw locking ensures secure, vibration-resistant connections on standard 35 mm DIN rails.

Overview

The set includes a grey polyamide terminal block with four push-in terminals and screw locking for reliable conductor retention. It mounts on NS 35/7.5 or NS 35/15 DIN rails and accepts solid conductors from 0.2 mm² to 6 mm², stranded conductors from 0.2 mm² to 4 mm², and AWG 24–10.

What stands out

• High rated surge voltage of 8 kV and overvoltage category III for demanding electrical environments
• Wide operating temperature range from -60 °C to 105 °C
• Flammability rating UL 94 V0 for enhanced fire safety
• Pollution degree 3 suitability for harsh industrial conditions

Technical details

• Type: Push-in terminal block, single-level
• Positions: 4
• Connection method: Push-in with screw locking
• Mounting: DIN rail (NS 35/7.5, NS 35/15)
• Nominal voltage (IEC): 800 V
• Nominal current (IEC): 32 A
• Rated surge voltage: 8 kV
• Conductor cross section (solid): 0.2–6 mm²
• Conductor cross section (stranded): 0.2–4 mm²
• Conductor cross section (AWG): 24–10
• Insulating material: Polyamide (PA)
• Colour: Grey
• Flammability rating (UL 94): V0
• Operating temperature: -60 °C to 105 °C
• Pollution degree: 3
• Overvoltage category: III

Our verdict

A dependable DIN rail terminal block with high electrical ratings and a wide temperature range, ideal for industrial applications where secure, maintenance-free connections are required.
