DeLOCK D-Type Module USB 2.0 Type-A female to female 90° angled

The DeLOCK D-Type Module provides a USB 2.0 Type-A female to female connection with a 90° angled interface, designed for installation in panels or cases with D-type openings. Its compact rectangular housing and flat mounting profile make it suitable for integrating USB devices in professional and space-constrained environments. The module is finished in black and measures 31 mm (W) × 33 mm (D) × 25 mm (H).

Advantages

The angled USB 2.0 Type-A female-to-female connector enables tidy cable routing and saves space behind panels. Its D-type module form factor allows straightforward mounting in standard D-type openings, reducing the need for custom cutouts. The black finish and compact dimensions contribute to a discreet, low-profile installation.

Suitable for

Key specifications

How to use

Mount the module into a compatible D-type opening on a panel or enclosure until it is seated securely. Connect USB Type-A cables or devices to each female port; the 90° orientation directs cables parallel to the panel to reduce stress and save depth. Ensure connected devices support USB 2.0 to maintain proper data rates and functionality.

Recommendations

For reliable operation, avoid applying excessive force to cables at the angled interface and ensure the surrounding panel provides adequate support. Use USB 2.0 cables and devices to match the module's specification; this module is intended for data connections rather than supplying high current for charging.
