DeLOCK D-Sub 15 pin female to RJ45 female Assembly Kit Red VGA RJ-45

The DeLOCK D-Sub 15 pin female to RJ45 female Assembly Kit (red) converts a VGA D-Sub 15 female connector to an RJ45 female connection, allowing a serial interface to be extended over an optional Cat.5/5e/6 cable. The compact assembly kit measures 23 mm × 40 mm × 16 mm, is manufactured in China and supplied in a polybag.

Advantages

This adapter kit allows individual pin assignment by inserting the cable conductor into the desired hole of the connector and locking it into the housing. The RJ45 female output together with the D-Sub 15 female input enables using standard network cabling to extend serial or VGA-style connections. Its small dimensions make it suitable for constrained installation spaces and easy to integrate into existing cabling setups.

Suitable for

• Extending a VGA/serial style D-Sub 15 connection over Cat.5/5e/6 cabling
• Custom pin mapping or one-to-one wiring projects
• Small installations where compact connector assemblies are required

Key specifications

• Brand: DELOCK
• Model / MPN: 67109
• EAN: 4043619671090
• Connector A: D-Sub 15 pin female (VGA style)
• Connector B: RJ45 female
• Dimensions (W × D × H): 23 mm × 40 mm × 16 mm
• Colour: Red
• Packaging: Polybag
• Country of manufacture: China

How to use

Prepare a Cat.5/5e/6 cable by stripping the outer jacket to expose the individual conductors. Insert each conductor into the selected hole of the D-Sub connector according to the required pin assignment and press it until it locks into the housing. Plug the assembled RJ45 end into the receiving RJ45 female port. Verify continuity and correct mapping with a multimeter or cable tester before final installation.

Recommendations

Use appropriate cable shielding and grounding where required for signal integrity. For reliable long-distance connections choose Cat.5e or Cat.6 cable and verify pin mapping according to the target device’s requirements.
