Dahua PFA111 PoE Injector Adapter – Gigabit, IEEE 802.3af, 48V, 15.4W

The Dahua PFA111 is a Gigabit Power over Ethernet (PoE) injector that combines data and power delivery over a single RJ45 cable. With a power output of 15.4W per port and compliance with IEEE 802.3af, it is an efficient solution for powering IP cameras, wireless access points, and edge network devices where power outlets are not readily available.

Advantages

This PoE injector simplifies network infrastructure by eliminating the need for separate power lines. It supports 10/100/1000 Mbps Ethernet speeds, ensuring compatibility with standard network equipment. The PFA111 features robust surge protection (4KV) and operates in a wide temperature range from -10°C to 55°C, making it suitable for both indoor and semi-outdoor installations.

Suitable for

• IP security cameras and video surveillance systems
• Wireless access points and routers
• VoIP phones and other IEEE 802.3af powered devices
• Network equipment requiring up to 15.4W of power

Key specifications

• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3af
• Input: 100-240V AC, 50/60Hz
• Output: 48V DC, 0.32A (15.4W)
• Ethernet ports: 1 data in, 1 PoE out (RJ45)
• Surge protection: 4KV
• Operating humidity: 5% – 95% RH non-condensing
• Housing: PC (polycarbonate) wall/desktop mountable

Recommendations

For optimal performance, use quality Cat5e or higher twisted-pair cable with a maximum distance of 100 meters between the injector and the powered device. Ensure the power source matches the input specifications and avoid exposing the unit to moisture or excessive heat beyond the rated operating conditions.
