Contact strip (Federleiste) Harting 09062486848, total contacts 48

Harting contact strip (Federleiste) with 48 total contacts is a spring-type contact element engineered for use in modular connector assemblies and cable harness applications. It provides 48 individual spring contacts arranged to match standard Harting-compatible housings, enabling secure electrical connections for signal or power circuits. The component is intended for repair, replacement, or integration when a compact, reliable 48-contact spring strip is required.

Advantages

The spring contacts offer consistent contact force and low insertion resistance to maintain reliable conductivity over repeated mating cycles. Its compact 48-contact layout supports high-density wiring while preserving mechanical stability inside compatible housings. The design is suitable for straightforward replacement or retrofit in existing connector modules, reducing downtime during maintenance. Materials and construction are chosen to provide electrical reliability and mechanical resilience in typical industrial and electronic assembly environments.

Suitable for (tasks / use cases)

• Repair or replacement of 48-contact Harting-compatible connector modules
• Manufacturing of cable harnesses and connector assemblies with a 48-contact requirement
• Prototyping and retrofitting electronic enclosures needing spring-contact interfaces
• Signal and low-to-moderate power connections where compact contact arrays are needed

Key specifications

• Contact type: spring (feder) contacts
• Total number of contacts: 48
• Intended use: signal and power contact points in connector assemblies
• Form factor: compact 48-contact strip sized for compatible housings
• Mechanical behavior: designed for repeated mating cycles with stable contact force

How to use

Install the contact strip into a housing or module designed for a 48-contact spring strip, ensuring correct orientation so each contact aligns with its mating pin or wire termination. During assembly, verify that the strip seats fully and that retention features of the housing engage to prevent movement. Terminate wires or insert mating connector pins according to the connector system instructions and confirm electrical continuity and insulation integrity before placing the assembly into service.

Recommendations

Handle the contact strip with care to avoid deforming individual spring elements. Use appropriate insertion tools or procedures recommended for the connector system to ensure correct seating. Inspect contacts visually and by continuity test after installation; replace the strip if any contacts show damage, corrosion, or poor conductivity.
