Ceiling light Steinel RS PRO R20 plus SC, round LED integrated 15.86 W, white, 350×55 mm, motion sensor

RS PRO R20 plus SC warm white is a round ceiling luminaire with an integrated 15.86 W LED module and a built-in high-precision HF motion sensor. Designed for corridors, kitchens and stairwells, the fixture measures 350 × 55 mm, delivers 1823 lm at 3000 K and uses an opal diffuser for even light distribution. The luminaire offers four lighting functions — basic light level, backlight, dimmable main light and emergency light — and can be configured and networked wirelessly via smartphone app. Emergency operation can alternatively be provided through connection to central battery systems.

Advantages

The Steinel RS PRO R20 plus SC combines sensor-controlled automation with app-based adjustment, enabling simple startup, interconnection and real-time tuning of light levels without ladders. Its HF sensor reaches up to 10 m for reliable presence detection, while the opal diffuser ensures uniform illumination. The product supports both battery-powered emergency modules and central battery connection, and the integrated LED has long rated life and energy-efficient performance.

Suitable for

• Corridors and hallways
• Kitchens
• Stairwells and landings
• Indoor communal areas requiring presence-controlled lighting

Key specifications

• Integrated LED, non-replaceable, 15.86 W
• Light output: 1823 lm; Color temperature: 3000 K (warm white); CRI: 82
• Dimensions: Ø 350 × 55 mm
• HF motion sensor range: up to 10 m
• IP rating: IP40; Indoor use
• Power supply: AC 220–240 V
• Emergency lighting: battery module or central battery system compatible

How to use

Install the RS PRO R20 plus SC on a suitable indoor ceiling surface (corridor, kitchen, stairwell) and connect to the AC mains according to local wiring regulations. Use the Steinel app to configure basic light level, backlight, dimmable main light and emergency settings, to group luminaires and to update firmware. For emergency operation, fit the optional battery-powered emergency module or connect the luminaire to a compatible central battery system as required.

Recommendations

For energy-efficient operation set presence detection and dimmed basic light; enable backlight only where continuous low-level illumination is desired. Verify compatibility of the optional emergency module or central battery with building systems before installation.
