CD-ROM Assembly Supermicro MCP-220-00006-00 5.25 inch SATA optical drive bracket and connector

Replacement CD-ROM assembly for Supermicro systems designed for 5.25-inch SATA optical drives. This assembly provides the mounting bracket and integrated SATA power and data connectors required to install a standard 5.25" optical drive into compatible Supermicro chassis. The unit is intended as a direct-fit service part to restore or upgrade drive bays in server and workstation systems that accept Supermicro form-factor components.

Advantages

This Supermicro CD-ROM assembly offers a ready-to-install bracket with pre-routed SATA power and data connectors, reducing installation time compared with generic mounting solutions. The assembly is made to align with Supermicro chassis mounting points and drive bay spacing to ensure proper fit and cable routing. Using a chassis-specific assembly helps maintain proper airflow, secure drive mounting and consistent electrical connections for SATA optical drives used in server environments.

Suitable for

• Replacing a faulty or missing 5.25" SATA optical drive bracket in compatible Supermicro chassis
• Upgrading systems by adding an internal SATA CD/DVD drive for software installation or media access
• Server maintenance tasks that require original-fit replacement parts to preserve warranty or compatibility
• Workstation or small server builds where correct drive bay alignment and cable routing are required

Key specifications

• Form factor: 5.25-inch optical drive bracket for internal installation
• Connector types: SATA data and SATA power connectors integrated into assembly
• Compatibility: Designed for fitment in compatible Supermicro chassis with corresponding drive bay layout
• Material and finish: metal bracket with connector mounting points for secure installation
• Mounting: screw-mount alignment matching standard 5.25" drive bay positions

How to use

Power down the system and disconnect mains power before beginning installation. Remove the chassis cover and locate the empty 5.25" drive bay; if replacing a part, remove the existing bracket or retainers first. Position the Supermicro CD-ROM assembly so the screw holes align with the drive bay and secure it with the appropriate screws. Slide the 5.25" SATA optical drive into the bracket and fasten the drive to the bracket using the drive mounting screws. Connect the SATA data cable from the motherboard or RAID controller to the drive's data connector and attach a SATA power cable from the system power supply to the drive's power connector. Reinstall the chassis cover, reconnect power and power on the system to verify the drive is recognized in BIOS/UEFI and the operating system.

Recommendations

Use anti-static precautions during installation and confirm chassis compatibility before purchasing. When adding optical drives in server environments, verify airflow and temperature impact; ensure cables are routed to avoid obstructing cooling paths. If the system uses hot-swap bays or proprietary backplanes, confirm whether this bracket is suitable or if a different interface is required.
