Brodit 146434 8MP Outdoor Network Bullet Camera with Forensic WDR, Lightfinder, OptimizedIR, PoE, IP66/IK10

Security teams monitoring perimeters, parking lots, or loading docks need a camera that delivers sharp, detailed footage around the clock. The Brodit 146434 bullet camera captures 4K UHD video at 25/30 fps, backed by Forensic WDR and Lightfinder technology to handle challenging lighting. Its varifocal lens (3.9–10 mm) offers a 109°–48° field of view, while OptimizedIR provides up to 40 m of night vision. Built for harsh environments, it carries IP66, IK10, and NEMA 4X ratings and operates from -40 °C to 60 °C. Power over Ethernet simplifies installation, and edge storage via microSD ensures local recording.

Key specifications

• 1/1.8" progressive scan RGB CMOS sensor, 8 MP (3840x2160)
• Varifocal P-Iris lens, 3.9–10 mm, F1.5, horizontal FOV 109°–48°
• Forensic WDR, Lightfinder, OptimizedIR up to 40 m (131 ft)
• H.264, H.265, and Motion JPEG video compression
• Two-way audio (line in/out), microSD/microSDHC/microSDXC slot
• 10/100 Mbps RJ45 Ethernet, PoE IEEE 802.3af/802.3at Type 1 Class 3
• IP66, IK10, NEMA 4X, operating temperature -40 °C to 60 °C
• AXIS Object Analytics, motion detection, tampering alarm

Why choose it

This camera excels in demanding outdoor scenes where lighting varies dramatically. Forensic WDR preserves details in both bright and dark areas, while Lightfinder delivers colour video in near darkness. The rugged housing withstands vandalism and weather, and PoE reduces cabling costs. With edge storage and analytics, it can operate standalone or as part of a larger system.

Ideal use cases

• Perimeter surveillance for warehouses and industrial sites
• Parking lot and entrance monitoring
• Loading dock and logistics areas
• Critical infrastructure protection

Good to know

The camera supports microSD cards for local recording, ensuring footage is retained even if the network fails. It is compatible with a wide range of VMS platforms via ONVIF. Installation is straightforward with PoE and the included mounting bracket. For optimal performance, pair with an AXIS network video recorder or compatible third-party NVR.
