Bose Professional FreeSpace FS FS2C In-Ceiling Loudspeaker 20W Black

The Bose Professional FreeSpace FS FS2C is a high-performance in-ceiling loudspeaker designed for commercial audio installations. Featuring a 2.25-inch full-range driver, it delivers clear, full-range sound for background music and paging applications. With a power handling of 20W RMS (80W peak) and a sensitivity of 86 dB SPL, this speaker provides consistent coverage with a wide 170° conical dispersion. The included 70/100V transformer allows for easy integration into constant-voltage systems, with multiple tap settings for flexible power adjustment. The black perforated steel grille and engineered plastic enclosure with steel backcan ensure durability and a discreet appearance. Ideal for retail spaces, offices, restaurants, and hospitality venues, the FS2C is easy to install using the included dog-leg clamps and requires a 160mm cutout.

Advantages

High-quality Bose sound in a compact, unobtrusive design. Wide 170° coverage ensures even sound distribution across large areas. Versatile transformer taps for 70V and 100V systems. Simple installation with dog-leg clamps. Durable construction suitable for indoor use.

Suitable for

• Retail stores and shopping malls
• Office buildings and conference rooms
• Restaurants and cafes
• Hotels and hospitality venues
• Educational facilities
• Background music and paging systems

Key specifications

• Speaker Type: In-ceiling loudspeaker
• Driver: 2.25-inch full-range
• Frequency Response (-3 dB): 83 Hz - 19 kHz
• Frequency Range (-10 dB): 70 Hz - 19 kHz
• Power Handling (RMS): 20 W
• Power Handling (Peak): 80 W
• Impedance: 16 Ohms (transformer bypass)
• Transformer Taps (70V): 1W, 2W, 4W, 8W, 16W
• Transformer Taps (100V): 2W, 4W, 8W, 16W
• Sensitivity: 86 dB SPL (1W/1m)
• Maximum SPL (Peak): 99 dB
• Coverage Angle: 170° conical
• Mounting: Ceiling-mount with dog-leg clamps
• Connectors: 6-pin Euroblock
• Colour: Black
• Enclosure Material: Engineered plastic with steel backcan
• Grille Material: Perforated steel
• IP Rating: IP33
• Cutout Diameter: 160 mm
• Mounting Depth: 119 mm

Recommendations

For optimal performance, pair with a compatible Bose Professional amplifier or DSP. Ensure proper ceiling support for secure installation. Suitable for indoor use only.
