BlueOptics PLC Splitter ABS Box, Input SC-UPC - Output SC-UPC 1x8, 1260 nm to 1650 nm, Single Mode

The BlueOptics PLC Splitter ABS Box is a high-performance planar lightwave circuit splitter designed for FTTx, PON, CATV, and data center applications. It provides reliable 1x8 splitting with SC/UPC connectors on both input and output, operating across the full 1260 nm to 1650 nm wavelength range. Housed in a compact ABS box, this splitter ensures low insertion loss, high return loss, and excellent uniformity.

Advantages

Low insertion loss (<10.5 dB) and high return loss (>50 dB) ensure minimal signal degradation. The splitter supports single-mode fiber (G.657.A1 / G.652.D) and offers polarization-dependent loss below 0.2 dB. Its robust ABS enclosure protects against harsh environments, with an operating temperature range of -40°C to +85°C.

Suitable for

• FTTx networks
• Passive Optical Networks (PON)
• CATV systems
• Data centers

Key specifications

• Split Ratio: 1x8
• Input Connector: SC/UPC
• Output Connector: SC/UPC
• Fiber Type: Single Mode (G.657.A1 / G.652.D)
• Wavelength Range: 1260 nm - 1650 nm
• Insertion Loss: <10.5 dB
• Return Loss: >50 dB
• PDL: <0.2 dB
• Uniformity: <0.8 dB
• Directivity: >55 dB
• Operating Temperature: -40°C to +85°C
• Pigtail Length: 1.0 m
• Enclosure: ABS Box

Recommendations

This PLC splitter is ideal for network operators requiring reliable and consistent optical splitting. Its compact design and wide temperature range make it suitable for both indoor and outdoor installations.
