BlueOptics Molex 747642301 Compatible BlueLAN QSFP+ to 4x SFP+ Breakout Direct Attach Cable (DAC) - Passive 40 Gbps to 4x 10 Gbps - 3m - Twinaxial Copper

The BlueOptics Molex 747642301 compatible BlueLAN QSFP+ to 4x SFP+ Breakout Direct Attach Cable (DAC) is a high-performance, passive twinaxial copper cable designed for 40 Gigabit Ethernet breakout applications. It enables seamless connectivity from a QSFP+ port to four SFP+ ports, ideal for data center interconnects, rack-to-rack, and server-to-switch connections. With a length of 3 meters and 30 AWG wire gauge, this cable ensures reliable signal integrity and low power consumption (0W).

Advantages

This breakout DAC cable offers a cost-effective and energy-efficient solution for high-speed data transmission. Its passive design eliminates the need for external power, reducing overall power consumption. The twinaxial copper construction provides excellent signal quality and durability, while the hot-swappable QSFP+ and SFP+ connectors allow for easy installation and maintenance. Compatible with Molex 747642301, it ensures seamless integration into existing networks.

Suitable for

• Data center interconnects
• Rack-to-rack connections
• Server-to-switch links
• High-performance computing environments

Key specifications

• Cable Type: Direct Attach Cable (DAC) - Breakout
• Configuration: Passive
• Aggregate Data Rate: 40 Gbps
• Breakout Data Rate: 4x 10 Gbps
• Connector A: QSFP+
• Connector B: 4x SFP+
• Cable Length: 3 meters
• Cable Material: Twinaxial Copper
• Wire Gauge: 30 AWG
• Impedance: 100 Ohm
• Compatibility: Molex 747642301
• Hot-Swappable: Yes
• RoHS Compliant: Yes
• Operating Temperature: 0°C to 70°C
• Power Consumption: 0W (Passive)
• Standards: SFF-8436 (QSFP+), SFF-8431 (SFP+)

Recommendations

For optimal performance, ensure that both the QSFP+ and SFP+ ports are compatible with passive DAC cables. This cable is ideal for short-range, high-speed connections within racks or between adjacent racks. Always handle with care to avoid damaging the connectors or cable.
