BlueOptics Lenovo A51P Compatible BlueLAN 10GBASE-CR Passive SFP+ Direct Attach Cable, 2m, AWG30 (A51P-BL)

The BlueOptics A51P-BL is a high-performance, passive Direct Attach Cable (DAC) designed for 10 Gigabit Ethernet connectivity. It is fully compatible with Lenovo A51P and other MSA-compliant SFP+ ports, providing a cost-effective and reliable solution for short-range data center and enterprise network connections.

Advantages

This passive twinax cable offers low power consumption (<0.1W), hot-swappable convenience, and robust construction with a PVC jacket. It ensures high-speed data transmission at 10 Gbps over a 2-meter length, ideal for server-to-server and storage area network (SAN) applications.

Suitable for

• Data centers requiring high-density cabling
• Server-to-server connections
• Storage Area Networks (SAN)
• Enterprise network upgrades

Key specifications

• Cable Type: Direct Attach Cable (DAC)
• Connector Type: SFP+ to SFP+
• Data Rate: 10 Gbps
• Ethernet Standard: 10GBASE-CR
• Cable Length: 2 meters
• Wire Gauge: 30 AWG
• Cable Technology: Passive Twinax
• Impedance: 100 Ohm
• Jacket Material: PVC
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Certifications: CE, FCC, RoHS
• Product Colour: Black

Recommendations

For optimal performance, ensure your network equipment supports SFP+ interfaces and 10GBASE-CR standards. This cable is plug-and-play, requiring no configuration.
