BlueOptics Compatible Amphenol NDAAFJ-0003 BlueLAN SC282801L5M26 QSFP28 Direct Attach Cable, 100GBASE-CR4, Infiniband EDR, 26AWG, 5 Meter (NDAAFJ-0003-BL)

The BlueOptics NDAAFJ-0003-BL is a high-performance QSFP28 Direct Attach Copper (DAC) cable, designed to be fully compatible with Amphenol NDAAFJ-0003 and BlueLAN SC282801L5M26. This passive copper cable delivers 100 Gbps data rates, supporting 100GBASE-CR4 Ethernet and InfiniBand EDR standards. With a length of 5 meters and 26 AWG wire gauge, it provides a reliable, low-latency connection for data center and high-performance computing environments.

Advantages

This DAC cable offers a cost-effective and energy-efficient solution for short-range high-speed interconnects. Its passive design ensures zero power consumption, while the QSFP28 form factor guarantees hot-swappable convenience. The 26 AWG construction maintains signal integrity over the 5-meter distance, making it ideal for top-of-rack to server connections.

Suitable for

• Data centers requiring 100G Ethernet or InfiniBand EDR connectivity
• High-performance computing clusters
• Storage area networks (SAN)
• Enterprise network upgrades

Key specifications

• Product Type: Direct Attach Copper (DAC) Cable
• Connector Type: QSFP28 to QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-CR4
• InfiniBand Standard: EDR (Enhanced Data Rate)
• Cable Length: 5 Meter
• Wire Gauge: 26 AWG
• Cable Material: Copper
• Transceiver Type: Passive
• Compatibility: Amphenol NDAAFJ-0003, BlueLAN SC282801L5M26
• Form Factor: QSFP28
• Protocol Support: Ethernet, InfiniBand
• Number of Lanes: 4
• Hot-Swappable: Yes
• Power Consumption: Low (Passive)

Recommendations

For optimal performance, ensure your network equipment supports QSFP28 ports and 100GBASE-CR4 or InfiniBand EDR. This cable is a direct replacement for Amphenol NDAAFJ-0003 and BlueLAN SC282801L5M26, offering identical functionality at a competitive price.
