BlueLAN Compatible Lenovo 00MP532 QSFP28 Direct Attach Cable, 100GBASE-CR4, Infiniband EDR, 30AWG, 2 Meter (00MP532-BL)

The BlueLAN SC282801L2M30 is a high-performance QSFP28 Direct Attach Cable (DAC) designed as a compatible replacement for the Lenovo 00MP532. It delivers 100 Gbps data rates over a 2-meter copper link, supporting both 100GBASE-CR4 Ethernet and Infiniband EDR standards. Ideal for data center and HPC environments, this passive cable ensures low latency and zero power consumption.

Advantages

Cost-effective alternative to OEM cables with identical performance. Passive design eliminates power usage and heat generation. Hot-pluggable QSFP28 connectors simplify installation and upgrades. Compliant with SFF-8665 MSA for broad interoperability.

Suitable for

• Data center top-of-rack to server connections
• High-performance computing clusters
• Network switch interconnects
• Infiniband EDR fabrics

Key specifications

• Cable Type: Direct Attach Cable (DAC)
• Transceiver Type: QSFP28
• Connector Type: QSFP28 to QSFP28
• Max Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-CR4
• Infiniband Standard: EDR
• Cable Length: 2 Meter
• Wire Gauge: 30 AWG
• Compatibility: Lenovo 00MP532 (OEM Equivalent)
• Cable Material: Copper
• Hot-Pluggable: Yes
• MSA Compliance: SFF-8665
• Power Consumption: Passive (0W)
• RoHS Compliant: Yes

Recommendations

For optimal performance, ensure your network equipment supports QSFP28 modules and 100GBASE-CR4 or Infiniband EDR. This cable is a direct replacement for Lenovo 00MP532 and is fully tested for compatibility.
