BLUELAN BlueOptics Infortrend 9624CM200CAB1-0030 QSFP56 Direct Attach Cable, 200GBASE-CR4, Ethernet, 30AWG, 2 Meter

The BLUELAN BlueOptics Infortrend 9624CM200CAB1-0030 is a high-performance QSFP56 Direct Attach Cable (DAC) designed for 200GBASE-CR4 Ethernet connectivity. This passive copper twinax cable delivers reliable, low-latency connections for data center and high-performance networking environments. With a length of 2 meters and 30 AWG wire gauge, it offers optimal signal integrity and flexibility for rack-to-rack or server-to-switch interconnects.

Advantages

This cable provides a cost-effective and energy-efficient solution for high-speed data transmission. Its passive design consumes less than 0.1W, reducing power and cooling costs. The QSFP56 connectors are hot-swappable and compliant with SFF-8665, ensuring easy installation and compatibility with a wide range of networking equipment. The 200 Gbps data rate supports bandwidth-intensive applications, while the 100 Ohm impedance and IEEE 802.3cd compliance guarantee stable performance.

Suitable for

• Data center interconnects
• High-performance computing clusters
• Server and storage connectivity
• Ethernet networks requiring 200GBASE-CR4

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Connector Type: QSFP56 to QSFP56
• Data Rate: 200 Gbps
• Ethernet Standard: 200GBASE-CR4
• Cable Length: 2 Meter
• Wire Gauge: 30 AWG
• Cable Material: Copper Twinax
• Impedance: 100 Ohm
• Power Consumption: < 0.1W
• Hot-Swappable: Yes
• Compliance: IEEE 802.3cd, RoHS, CE, FCC

Recommendations

For optimal performance, pair this cable with compatible QSFP56 ports on switches, servers, or storage devices. Ensure your equipment supports 200GBASE-CR4 and SFF-8665 for seamless integration.
