Berker 6710098989 KNX Push-button Sensor 4-gang Polar White B.IQ

The Berker 6710098989 is a high-quality KNX push-button sensor from the Berker B.IQ design line, featuring 4 programmable buttons in a glossy polar white finish. Designed for flush mounting, this device integrates seamlessly into modern smart home systems, offering intuitive control over lighting, blinds, and scenes via the KNX bus.

Advantages

This push-button sensor provides flexible and reliable control for KNX installations. With four individually programmable buttons and integrated LED status indicators, it allows for switching, dimming, blind control, value transmission, and scene activation. The high-gloss thermoplastic surface is both durable and aesthetically pleasing, complementing Berker B.IQ frames.

Suitable for

• Smart home KNX systems requiring multi-functional wall-mounted control
• Residential and commercial buildings with Berker B.IQ design frames
• Applications needing switching, dimming, blind, or scene control

Key specifications

• Product Type: KNX Push-button Sensor
• System: KNX (Konnex)
• Number of Buttons: 4-gang
• Colour: Polar White (similar to RAL 9010)
• Material: Thermoplastic, high-gloss
• Design Line: Berker B.IQ
• Mounting: Flush-mounted
• Bus Connection: KNX Bus Terminal
• Operating Voltage: Via KNX Bus
• Functions: Switching, Dimming, Blind Control, Value Transmitter, Scene Control
• Status Indication: LED per button
• Programming: ETS Software
• Protection Class: IP20
• Operating Temperature: 0 to +45 °C
• Relative Humidity: 5 to 95 % (non-condensing)
• Surface Finish: Glossy
• Compatibility: Berker B.IQ frames
• Integrated Bus Coupler: Yes

Recommendations

For optimal performance, pair this push-button sensor with Berker B.IQ frames and program using ETS software. Ensure KNX bus power is available. Suitable for indoor use only.
