BCS Universal AC/DC Power Adapter 12V 1.7A 20.4W BCS-ADU170

The BCS Universal AC/DC Power Adapter BCS-ADU170 is a high-quality switching power supply designed to provide reliable and efficient power for a wide range of 12V DC devices. With an output of 12V/1.7A (20.4W), this wall-mount adapter is ideal for CCTV cameras, LED lighting, routers, and other electronic equipment. It features a standard 5.5mm x 2.1mm DC barrel jack with center positive polarity, ensuring compatibility with many devices. The adapter is built with flame-retardant ABS plastic and includes multiple protection features for safe operation.

Advantages

This universal power adapter offers versatility and reliability. Its switching mode technology ensures high efficiency and stable output, while the compact wall-mount design saves space. The adapter is certified with CE and RoHS, meeting international safety and environmental standards. It operates over a wide input voltage range (100-240V AC) and includes over-voltage, over-current, and short-circuit protection for peace of mind.

Suitable for

• CCTV cameras and security systems
• LED strip lights and lighting fixtures
• Routers, switches, and networking equipment
• General 12V DC powered devices

Key specifications

• Product Type: AC/DC Power Adapter
• Input Voltage: AC 100-240V, 50/60Hz
• Output Voltage: DC 12V
• Output Current: 1.7A
• Output Power: 20.4W
• DC Connector: 5.5mm x 2.1mm DC Barrel Jack, Center Positive
• Form Factor: Wall-mount Plug-in
• Technology: Switching Mode Power Supply (SMPS)
• Protection: Over-voltage, Over-current, Short-circuit
• DC Output Cable Length: Approx. 1.2 meters
• Operating Temperature: -10°C to 50°C
• Certifications: CE, RoHS
• Housing Material: Flame-retardant ABS Plastic

Recommendations

For optimal performance, ensure that the device you are powering requires 12V DC and draws no more than 1.7A. This adapter is not suitable for devices requiring higher current or different voltage. Always check polarity before connecting.
