BCS LINE BCS-APTZ3 PoE Adapter for PTZ Cameras - 24V AC, 30W, Black

Power your BCS LINE PTZ camera in locations where a standard power outlet is unavailable. The BCS-APTZ3 adapter takes a single PoE network cable and splits it into separate 24V AC power and 10/100 Mbps Ethernet data, simplifying installation on walls, ceilings, or poles.

Key specifications

• Converts IEEE 802.3af/at PoE input (48-56V DC) to 24V AC output for PTZ cameras
• Supports up to 30W power output, sufficient for pan-tilt-zoom motors and heaters
• Maintains 10/100 Mbps data transmission for smooth video streaming
• Compact black plastic housing with wall/surface mounting options
• Built-in overload, short circuit, and ESD protection for reliable operation
• Operating temperature range: -10°C to +50°C, suitable for indoor and sheltered outdoor use

Why choose it

This adapter eliminates the need for separate power cabling, reducing installation time and cost. It's specifically designed for BCS LINE PTZ cameras, ensuring compatibility and stable performance in security and surveillance setups.

Ideal use cases

• Retail stores and warehouses monitoring large areas with PTZ cameras
• Office buildings where running AC power to camera locations is impractical
• Parking lots and building exteriors with existing PoE network infrastructure
• Upgrading legacy PTZ cameras to PoE without replacing the camera itself

Good to know

The adapter includes one RJ45 PoE input, one RJ45 data output, and a 2-pin terminal block for AC power connection. It does not include a power supply or mounting screws, so plan accordingly for your installation.
