Bath lift DIETZ Kanjo ECO PLP004 with upholstery — adjustable height, battery 14.4V, max user weight 140 kg, collapsible, blue

DIETZ Kanjo ECO PLP004 is a collapsible bath lift with upholstery designed to assist with safe and comfortable transfers into and out of the bathtub. Constructed from glass fiber reinforced polypropylene and finished in blue, the lift offers a compact and lightweight solution for home bathing. It features an adjustable seat height from 6.5 to 45.5 cm, an adjustable backrest with a 40° range, and is controlled via buttons or a remote. The unit is battery powered (14.4 V, 2150 mAh) and supports a maximum user weight of 140 kg. Regular inspections for damage are recommended.

Advantages

The bath lift combines a reinforced, water-resistant polypropylene structure with upholstery for added comfort while remaining lightweight at 10.8 kg. Its collapsible design and compact dimensions make storage and transport easier. Electric adjustment via buttons or remote enables smooth seat height and backrest position changes without manual lifting. Battery operation avoids the need for a constant mains connection, increasing portability within the home.

Suitable for

• People with reduced mobility who need assistance entering or leaving a bathtub
• Home caregivers who require a portable, easy-to-store bathing aid
• Users who prefer electric seat height and backrest adjustment

Key specifications

• Material: Glass fiber reinforced polypropylene
• Product colour: Blue
• Seat height range: 6.5–45.5 cm
• Backrest angle range: 40°
• Maximum user weight: 140 kg
• Power source: Battery, 14.4 V
• Battery capacity: 2150 mAh
• Control type: Buttons and remote
• Weight: 10.8 kg
• Seat width: 37.5 cm
• Seat depth: 50 cm
• Maximum width: 71 cm; Minimum width: 35 cm
• Backrest height: 68 cm
• Seat depth (front-to-back): 50 cm
• Stand width: 29.5 cm; Stand depth: 56.5 cm
• Depth (min): 90 cm
• Maximum height: 110.5 cm

How to use

Place the folded bath lift into the bathtub and unfold it according to the included instructions, ensuring the stand and supports sit securely on the tub surface. Power the unit by connecting or ensuring the battery is charged, then use the buttons on the unit or the remote control to lower the seat into the tub, set the desired seat height between 6.5 and 45.5 cm, and adjust the backrest within its 40° range for a comfortable position. Transfer onto the seat while it is at a safe height, operate the controls to move into the bathing position, and reverse the process to exit. After use, fold the lift for storage if required and recharge the battery as needed.

Recommendations

Regularly check the bath lift for damage and wear. Verify battery charge before use and follow the manufacturer's maintenance instructions to ensure safe operation and maximum service life.
