BACHMANN Spiral Power Cable H05VV-F 3G1.5mm² Black 4.0m with ISV Locking Mechanism (BM0010696)

The BACHMANN BM0010696 is a high-quality spiral power cable designed for industrial power distribution and flexible connections. With a length of 4.0 meters and a robust H05VV-F 3G1.5mm² configuration, this cable ensures reliable performance in demanding environments. The integrated ISV locking mechanism provides secure connections, preventing accidental disconnection.

Advantages

This spiral cable offers excellent flexibility and durability, making it ideal for applications where frequent movement or tight spaces are involved. The ISV locking mechanism guarantees a secure fit, reducing downtime and enhancing safety. The black PVC sheath provides protection against wear and tear, while the fine-stranded copper conductors ensure optimal conductivity.

Suitable for

• Industrial power distribution systems
• Flexible connections in workshops and factories
• Power supply for machinery and equipment
• Temporary power setups requiring secure locking

Key specifications

• Cable Type: H05VV-F
• Conductor Configuration: 3G (3 cores including protective earth)
• Conductor Cross-section: 1.5 mm²
• Cable Length: 4.0 m
• Cable Colour: Black
• Rated Voltage: 300/500 V
• Insulation Material: PVC
• Sheath Material: PVC
• Conductor Material: Copper
• Conductor Type: Fine-stranded, flexible
• Cable Design: Spiral / Coiled
• Special Feature: ISV Locking Mechanism
• Max. Conductor Temperature: 70 °C
• Operating Temperature Range (Flexible Use): +5 °C to +70 °C
• Flame Retardancy: Yes, according to EN 60332-1-2

Recommendations

For optimal performance, ensure the cable is used within its specified temperature range and avoid exceeding the rated voltage. The spiral design allows for easy storage and reduces tangling. Suitable for both indoor and outdoor applications where protected from direct weather exposure.
